ZH-X Pro Automatic Folder Gluer(Modylar)

Electric displacement, PLC touch screen, NSK bearings, upgradeable, pneumatic lift, synchronous drive.

1. Smart Control
Electric displacement & PLC touch screen enable easy debugging and precise operation.

2. Durable Transmission
Imported NSK bearings with hexagonal shaft ensure superior wear resistance and long life.

3. Upgradeable & Safe
Later upgrade to hook bottom/hexagonal; pneumatic lift and protective cover ensure safe production.

1.Equipped with electric displacement and easy debugging

2.Display screen,PLC touch screen

3.Paper feeding patent self weight knife,convenient forpaper separation

4.The main bearings are imported NSK,and the transmission shaft is a hexagonal shaft for better wear resistance

5.In the later stage,the function can be upgraded to hook bottom and hexagonal machines

6.Pneumatic lifting plate,gantry structure

7.Synchronous belt drive,beautiful protective cover,safe production

8.Double side squeezing function,secondary line pressing function,precise pasting of corrugated boxes

Parameter	ZH-1250X Pro	ZH-1450X Pro	ZH-1650X Pro	ZH-1850X Pro
Product Name	Automatic Folder Gluer (Modular)
Paper Material	210-600g/m² paperboard. Compatible with A/B/C/E/F corrugated and double-wall corrugated board
Max. Liner Speed	0-300m/min continuous adjustment
Feeding Way	Automatic feeding
Way of Folding	single side gluing
Glue Material	Cold glue
Electric Power	13KW AC3PH380V	15KW AC3PH380V	17KW AC3PH380V	20KW AC3PH380V
Weight	6000kg	6200kg	6400kg	600kg
Over Dimension (M)	14.221.8	14.22.21.8	14.22.41.8	14.22.61.8
