Crash-Lock Bottom Box Automatic Folder Gluer Machine PRINTYOUNG Brand Paper Packaging Electric 220V Zhejiang Origin
Description
Crash-lock Bottom Box Automatic Folder Gluer Machine
ZH-D series is the updated model on the basis of ZH-G series.
Difference from ZH-G series
1, ZH800D adds the upper belt on the folding unit to improve the stability of the box moving.
2, The upper belt equipped with lifting devices, more convenient to operate.
3, Main engine power has been increased and the speed is faster.
4, Pressing unit has separate motor to control speed, only when there comes the box, the pressing section works..
5, The machine outlook is more beautiful.
Specifications
1. Line speed:0—260m/min adjustable |
2. Paper Range:210-600g/m2 paperboard |
3. The forming of pasting box:pre fold, fold from either side, bottom fold |
4. Auto Feeding |
5. Line of folding: 1st, 2nd and 4thline can do 180°folding,3rd line 135° |
6. Glue: water solvable |
7. Gluing: four stations, 2 upper stations, 2 lower stations. Each lower station has a grinding wheel for cleaning UV varnish and ink off the flap before gluing. |
8. Grinding Speed: 6000 round/ min |
9. Electric 5.5Kw AC 3phase 380V |
10. Weight:2600kg |
11. Dimension:8500*900*1300(mm) |
12. Auto Counting Range: 0-999999 No. with batching facility. |
Technical Data
Model |
Box type |
(A Max) |
(A Min) |
(B Max) |
(B Min) |
(C Max) |
(C Min) |
(D Max) |
(E Min) |
ZH-800D |
Straight line box(I) |
560 |
106 |
500 |
65 |
270 |
50 |
7 |
6 |
Pre-fold box(I) |
560 |
180 |
500 |
65 |
270 |
90 |
10 |
6 |
|
Crash lock bottom box(II) |
560 |
160 |
500 |
65 |
270 |
80 |
40 |
6 |
|
ZH-880D |
Straight line box(I) |
660 |
110 |
500 |
65 |
320 |
50 |
7 |
6 |
Pre-fold box(I) |
660 |
180 |
500 |
65 |
320 |
90 |
10 |
6 |
|
Crash lock bottom box(II) |
660 |
160 |
500 |
65 |
320 |
80 |
50 |
6 |
|
ZH-1000D |
Straight line box(I) |
760 |
130 |
600 |
80 |
370 |
60 |
10 |
8 |
Pre-fold box(I) |
760 |
180 |
600 |
80 |
370 |
90 |
15 |
8 |
|
Crash lock bottom box (II) |
760 |
180 |
600 |
80 |
370 |
90 |
60 |
8 |
Box Samples:
Optional:
